6U VITA62 VPX Power Supply 3Phase 115VAC Input

PCI Power Systems e.K. manufactures a variety of rugged modular conduction cooled and convection cooled VITA62 VPX Power Supplies in 3U and 6U form factor. The power supplies are with are designed, digitally controlled poly-phase technology on all voltage rails to minimize EMI/EMC, SSC on all stages and high reliability.

The products are available in 28V/ 270VDC /115VAC / 230VAC Single and Three Phase with power rating from 500W to 2400W. They are designed and build to meet Mil-EMI/EMC and Environmental standards. Single and Double Slot in Conduction and Air cooled models.

6U VITA62 VPX Power Supply 3 Phase 115VAC Input

ModelForm FactorStyleTypeInputPowerFeaturesCooling
PCI_800.311 6U, 1"VITA 62AC1P 115VAC1200W150ms holdupConduction
PCI_800.310 6U, 1"VITA 62AC3P 115 VAC660W40ms holdupConduction
PCI_800.319 6U, 1.6"VITA 62AC3P 115 VAC1200WConduction
NewPCI_800.323 6U, 1"VITA 62AC3P 115 VAC1400W50Hz/400HzConduction
NewPCI_800.318 6U, 1.6"VITA 62AC3P 115 VAC1800WConduction
NewPCI_800.322 6U, 3"VITA 62AC3P 115 VAC3600W50Hz/400HzConduction
